Air Rv Diesel Heater And Water Heater Liquid 10kW 12v

I'm Online Chat Now

Air Rv Diesel Heater And Water Heater Liquid 10kW 12v

Air Rv Diesel Heater And Water Heater Liquid 10kW 12v
Air Rv Diesel Heater And Water Heater Liquid 10kW 12v Air Rv Diesel Heater And Water Heater Liquid 10kW 12v

Large Image :  Air Rv Diesel Heater And Water Heater Liquid 10kW 12v

Product Details:
Place of Origin: China
Brand Name: HLN
Certification: E-Mark
Model Number: 10kW Coolant Heater
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $ 360-370 set
Packaging Details: 52x33x29cm carton
Delivery Time: 10 work days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 5000 per month

Air Rv Diesel Heater And Water Heater Liquid 10kW 12v

Heating Capacity, Part Load/full Load (kW): 4.4/10.3 Fuel Consumption, Part Load/full Load (l/h): 0.51/1.29
Working Voltage (V): 12/24 Power Consumption, Part Load/full Load (W): 74.4/104.4
Weight (kg): 7 Outline Dimensions (L X W X H) (mm): 435X212X177
Operating Ambient Temperature (℃): -41 To +55 Storage Temperature (℃): -55 To +70
Key Word 1: Liquid Diesel 10kW Water Parking Heater Key Word 2: Engine Coolant Preheater
Key Word 3: Tractor Truck Coolant Heater Product: Liquid Diesel 10kW Water Parking Heater Engine Coolant Preheater Tractor Truck Coolant Heater
High Light:

rv diesel air heater HLN


rv diesel heater 10kW 12v HLN


diesel air heater rv HLN

HLN Aquano 10k Coolant heater

Liquid Diesel 10kW Water Parking Heater Engine Coolant Preheater Tractor Truck Coolant Heater


Heating capacity, part load/full load (kW)4.4/10.3
Fuel consumption, part load/full load (l/h)0.51/1.29
Working voltage (V)12/24
Power consumption, part load/full load (W)74.4/104.4
Weight (kg)7
Outline dimensions (L x W x H) (mm)435x212x177
Operating ambient temperature (℃)-41 to +55
Storage temperature (℃)-55 to +70

An HLN coolant heater integrates seamlessly into the engine coolant loop, providing an independent heating source. Within the HLN coolant heater system, the metering pump connects to the existing fuel tank, supplies diesel fuel to the heater for combustion. The circulation pump draws engine coolant into the heater. The heater heats up the coolant, and the coolant continues to warm up the engine block to avoid cold start, or keep the engine operating in a desired temperature. As a result, engine wear is reduced, and the vehicle cabin can be warm without idling the engine.
All of the HLN heaters need to go through rigorous tests before they can hit the market. Conducting in-situ extreme cold environment tests is a standard process for the company as new lines of HLN heaters become available. The company has done multiple tests at an environment temperature of lower than -45°C. In the tests, all air heaters of 2KW, 4KW, 7KW, and water heaters of 5KW, 10KW, 12KW and 15KW are able to start and operate smoothly. In addition, lab tests simulating low temperature (-41°C) and high elevation environments, salt spray, water splash, and electro-magnetic field interference are required for HLN heaters.
The 10kw heater is a multi-function of environmental protective and highly intelligent remote control parking heater. The main heater is a small fuel furnace controlled by a single-chip microprocessor. Its medium circulation system is connected with the cooling system of an automobile engine. In such a way, the cooling liquid for the engine can be heated by the heater while the engine is not working. The heater not only can heats compartment and restroom to a proper temperature but also preheats medium and large engines, so as to avoid cold starting and increase the service life of engines. Heaters can offer comfortable temperature during the set period. This allows for maximum relaxation and recuperation of the driver, obviously increased the safety of driver and cargo. Heaters can avoid idling and cutting the cost, carbon dioxide and fuel consumption can be reduced. Make a great contribution to environment protection. Car heater fun.
Product Characteristics
· Delivery terms can be customized.
· Both as original and installation equipment.
· Work at any time even in the low ambient temperature.
· Eliminate idling and reduce fuel consumption.

  1. Are you a factory of a trading company?

        We are a professional manufacture for diesel heater with 40 years of expertise and experience.

  1. Can you make products with our brand

  Surely, we are welcome to cooperate with OEM service.

  1. Do you have quality warranty?

  Yes, we have quality warranty under normal condition. Please contact us for details

  1. Why will you choose us?

 Comparing with other manufacturers, the advantages of our Heater are experience, quality, capacity and price.

 Firstly, we have 40 years of experience and expertise to dominate this field. We are the earliest manufacturer in China.

 Secondly, the quality of our heater is the best in China and the top 3 in the world, and we are the only Chinese heater company in the OEM   equipment supplier field for world's top players such as FAW Group, Sany Group and Zoomlion.

 Thirdly, we produced and sold 200 thousand machines last year as the No.1 sales volume in China.

 Finally, our quality and technology is closed to Webasto and Eberspacher but the price of our product is much more reasonable, not only the   heater but also the accessories.
